SF6 Gas Moisture Analyzer

WS-2 SF6 Gas Moisture Analyzer introduction:

The Intelligent Dew Point Analyzer represents the pinnacle of precision moisture measurement. By integrating European sensing technology with advanced automation, this instrument ensures unmatched data stability and accuracy. It features a wide measurement range, rapid response times, and an intuitive user interface with a high-visibility display. Designed for versatility, it is ideal for testing humidity in air, nitrogen, and inert gases. It is particularly optimized for SF6 gas moisture analysis within power systems, petrochemical plants, metallurgical industries, and research institutes

1. Portable design: The instrument is light and easy to carry and use.
2. Fast speed: the instrument can make the test as soon as it starts up, fast to get the test results for humidity.
3. Fast and save gas: it only costs about 2L(101.2kPa) when testing.
4. Self-lock joint: use the self-lock joint imported from Germany, safe and reliable, without gas leakage.
5. Data storage: high capacity, can store 50 groups of test results at the most.
6. Clearly display: the dew point, micro-water(ppm), temperature, humidity, time and date, and battery capacity are displayed by LCD.
7. RS232 interface: can connect with the printer and print the test results.
8. Built-in power supply: built-in 4Ah chargeable battery, filled one time can work for 10 hours.

Q: Water is not conductive at low quantities. Why is it so dangerous inside an SF6-filled compartment?

A: It is all about the chemistry under an electric arc. While pure SF6 is inert, moisture acts as a catalyst for destruction.

The Reaction: When an arc occurs (during switching or partial discharge), SF6 breaks down. If H2O is present, it reacts with these by-products to form Hydrofluoric Acid (HF) and Sulfuric Acid (H2SO4).

The Damage: These acids aggressively etch the surface of epoxy resin insulators (basin insulators), creating a rough, carbonized path.

The Catastrophe: Eventually, this leads to a surface flashover and catastrophic failure of the GIS, even if the gas pressure remains within normal limits.

Q: My analyzer shows both Dew Point and PPMv. I'm confused about which one to record in the test report.

A: For modern engineering, PPMv (parts per million by volume) is the safer choice for reporting.

The Reason: Dew point is pressure-dependent. A reading of -40°C at atmospheric pressure is NOT the same as -40°C at rated operating pressure (e.g., 0.5 MPa).

The Standards: International standards like IEC 60480 recommend using PPMv or normalizing the Dew Point to 20°C at atmospheric pressure to ensure data consistency.

Rule of Thumb: If you report in Dew Point, you MUST include the pressure reading at the time of measurement. Without pressure data, a dew point reading is meaningless.

Q: My analyzer shows 250 PPMv for a 220kV circuit breaker. Should I be worried?

A: Yes, that is an immediate "Action Required" signal.

New Gas: Should be extremely dry, typically < 8 ppmv.

In-Service Limit (IEC 60480): For equipment rated > 72.5kV, moisture should generally be < 150 ppmv.

The Danger Zone: Anything above 200 ppmv (or a dew point higher than -36°C normalized) indicates significant contamination. You must perform gas recycling (drying) or replacement to prevent long-term acid damage to the insulators.
