Product Introduction
XZB- 1200KVA 600KV AC Resonance Test System
I. Tested application and requirement
II. Work condition
environment temperature：－100C –50 0C;
relative humidity：≤90%RH;
altitude: ≤1000m;
III. Main technical parameters and functions
rated capacity：1200kVA;
input power： 3 phase 380V, 50Hz;
rated voltage：600kV;
rated current： 2A;
working frequency：30-300Hz;
output waveform： sine wave
waveform deviation factor： Distortion rate of output voltage waveform≤1%;
working time ：under rated load allowed continuous working 60min; over voltage 1.1 times 1min;
Temperature rise：u nder rated load allowed continuous working 60min, after that temperature rise≤65K
quality factor： Q≥30(f=45Hz)
defensive function: Over-current, over-voltage,,e and flashover protection are provided for the tested product (see frequency conversion power supply for details).
accuracy： System effective value 1.5;
IV. XZB-1200KVA 600KV AC Resonance Test System Test standard
GB10229-88 《reactor》
GB1094 《power transformer》
GB50150-2006 《the standard for electrical equipment handover and commission test》
DL/T 596-1996 《preventive testing rule of electrical equipment》
GB1094.1-GB1094.6-96 《Shell protection grade》
GB2900 《electrotechnical terminology》
GB/T16927.1~2-1997 《High voltage test technique》
AC resonant test system operation video
Product Parameter
XZB-1200KVA 600KV AC Resonance Test System application
|
Combination Test object |
Reactor 400kVA/200kV*3 |
Excitation transformer output selection |
Test voltage (kV) |
|
400KV GIS |
Use 3 reactors in series |
25kV |
≤520kV |
Product Feature And Application
XZB-1200KVA 600KV AC Resonance Test System equipment list
|
no |
name |
Model and specification |
unit |
Qty |
remarlk |
|
1 |
Exciting transformer |
JLB-55kVA/25kV/0.4kV |
set |
1 |
|
|
2 |
variable-frequency power supply |
CHXB-F-55kW/380V |
set |
1 |
|
|
3 |
High voltage reactor |
DK-400kVA/200kV |
set |
1 |
|
|
4 |
capacitive voltage divider |
FRC-600kV/500pF |
set |
1 |
|
|
6 |
Internal connection wires |
set |
1 |
document list
|
No |
name |
unit |
qty |
remark |
|
1 |
Ex-Factory test report |
set |
1 |
|
|
2 |
manual |
set |
1 |
Prodection Details
FAQ
1. Delivery： Fast delivery and Flexible mode of transportation
2. Payment: Choose payment terms and payment method that is convenient
3. Sale service: 24-hour online contact, choose the right model of equipment according to your request, give the best offer, support customization
4. Warranty period: All machine quality guarantees one year of lifetime technical support for you. Online response to customers' technical problems.
