During the transformer testing process, as a power engineer, we may encounter various problems during the operation. Through the following questions and answers about CT PT measurment, we can acquire very important knowledge and information.



FAQ 1: What is Ratio Error, and why are 0.2s Class CTs so strict?

Q: Ratio error of 0.05%? Why does a metering CT need to be so much more accurate than a protection CT?

A: Ratio error is the % difference between nameplate and measured. 0.2s means "Special" accuracy down to 1% current. It is about the "Honesty" of the electric bill.

FAQ 2: Polarity - The "Veto" in Differential Protection

Q: What happens if my ratio is perfect but polarity (S1/S2) is reversed?

A: The protection system will commit "Suicide." The relay will see a massive false fault current.

Differential Logic (87 Relay):

• Correct Polarity: 100A In - 100A Out = 0A difference. ✅

• Reversed Polarity: 100A In - (-100A Out) = 200A difference. ❌

• Result: Instant false trip. You cannot energize the station.

FAQ 3: Phase Displacement (Angle Error) and the Electric Bill

Q: Why does a small "Phase Error" (e.g. 15 minutes) matter if the magnitude is correct?

A: Because Active Power P = V * I * cos(phi). Phase displacement shifts the timing of the current wave.

The Accuracy Trap:

• Meters measure the ANGLE between V and I.

• On low-power-factor loads (e.g. cos phi = 0.5), a 15-min error causes 1% error in power.

FAQ 4: Modeling Method - verifying 1000A with only 120V

Q: Traditional tests push 1000A through the primary. How can the analyzer be accurate without it?

A: It uses the "Modeling Method." It separates physical geometry (turns) from magnetic losses.

How it works:

❶ Turns Ratio: High-precision voltage bridge measures Ns/Np.

❷ Magnetic Model: Excitation curve captures exactly how much current the iron core "steals."

❸ Math Prediction: Computer combines Turns + Loss + Burden to predict 1000A error.

FAQ 5: Field Reliability - 0.1% accuracy in a noisy substation

Q: Won't substation interference ruin a 0.1% precision measurement?

A: Analyzers use Narrow-band Digital Filtering and Frequency Shifting to stay quiet.

Noise Rejection Tactics:

• Frequency Shifting: Injects signals at 49.7 Hz or 50.3 Hz. Ignores 50 Hz background noise.

• Internal Reference: Self-calibrates against ultra-stable internal voltage references.

• Kelvin 4-Wire: Eliminates the resistance of your own test leads.
